无人机电池
Model | Voltage | Capacity | Cell Dimension Max.(mm) | Internal Impedance | Tab Width | Tab Distance | Weight | Max Discharge Current | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
V | mAh | T | W | L | mΩ< | mm | mm | g | Max.Cont | Burst | Max Cont.(A) | Burst(A) | ||
HCG453048SP | 3.7 | 450 | 4.5 | 30 | 48 | 16 | 6 | 20 | 12 | 25C | 50C | 11.25 | 22.5 | |
HCG502562SP | 3.7 | 600 | 5.3 | 25 | 62 | 14 | 7 | 17 | 16 | 25C | 50C | 15 | 30 | |
HCG603048SP | 3.7 | 600 | 5.5 | 30 | 49 | 15 | 7 | 20 | 16 | 25C | 50C | 15 | 30 | |
HCG783048SP | 3.7 | 850 | 7.6 | 30 | 48 | 12 | 9 | 20 | 21 | 25C | 50C | 21.25 | 42.5 | |
HCG603562SP | 3.7 | 1000 | 5.8 | 35 | 62 | 8 | 11 | 23 | 26 | 25C | 50C | 25 | 50 | |
HCG403496SP | 3.7 | 1100 | 4 | 34 | 96 | 8 | 11 | 22 | 28 | 25C | 50C | 27.5 | 55 | |
HCG753562SP | 3.7 | 1200 | 7.5 | 35 | 62 | 6 | 12 | 23 | 30 | 25C | 50C | 30 | 60 | |
HCG553496SP | 3.7 | 1500 | 5.5 | 34 | 96 | 6 | 12 | 22 | 38 | 25C | 50C | 37.5 | 75 | |
HCG605060SP | 3.7 | 1500 | 6 | 50 | 60 | 8 | 12 | 33 | 36 | 25C | 50C | 37.5 | 75 | |
HCG723090SP | 3.7 | 1600 | 7.2 | 30.5 | 90 | 5 | 12 | 20 | 40 | 25C | 50C | 40 | 80 | |
HCG753496SP | 3.7 | 2100 | 7.5 | 34 | 96 | 5 | 13 | 22 | 50 | 25C | 50C | 52.5 | 105 | |
HCG8334106SP | 3.7 | 2600 | 8.3 | 34 | 106 | 4 | 15 | 22 | 62 | 25C | 50C | 65 | 130 | |
HCG883496SP | 3.7 | 2600 | 8.6 | 34 | 96 | 4 | 15 | 22 | 61 | 25C | 50C | 65 | 130 | |
HCG5543128SP | 3.7 | 2800 | 5.7 | 43 | 128 | 4 | 15 | 28 | 68 | 25C | 50C | 70 | 140 | |
HCG6843128SP | 3.7 | 3200 | 7 | 43 | 128 | 4 | 15 | 28 | 78 | 25C | 50C | 80 | 160 | |
HCG7042125SP | 3.7 | 3400 | 7 | 42 | 125 | 4 | 15 | 28 | 80 | 25C | 50C | 85 | 170 | |
HCG7842125SP | 3.7 | 3700 | 7.8 | 42 | 125 | 3 | 15 | 28 | 86 | 25C | 50C | 90 | 180 | |
HCG8242125SP | 3.7 | 4000 | 8.2 | 42 | 125 | 3.5 | 16 | 28 | 96 | 25C | 50C | 100 | 200 | |
HCG7543150SP | 3.7 | 4000 | 7.5 | 43 | 150 | 3 | 16 | 28 | 97 | 25C | 50C | 100 | 200 | |
HCG8043125SP | 3.7 | 4100 | 8 | 43 | 125 | 3 | 16 | 28 | 109 | 25C | 50C | 112.5 | 225 | |
HCG9545135SP | 3.7 | 5000 | 9.2 | 45 | 135 | 3 | 17 | 30 | 121 | 25C | 50C | 125 | 250 | |
HCG1043128SP | 3.7 | 5000 | 10 | 43 | 128 | 3 | 17 | 28 | 118 | 25C | 50C | 125 | 250 | |
HCG1042125SP | 3.7 | 5000 | 10 | 42 | 125 | 4 | 17 | 28 | 117 | 25C | 50C | 125 | 250 | |
HCG9845135SP | 3.7 | 5000 | 9.8 | 45 | 135 | 4 | 17 | 30 | 114 | 25C | 50C | 125 | 250 | |
HCG9546148SP | 3.7 | 6000 | 9.5 | 46 | 148 | 4 | 18 | 30 | 141 | 25C | 50C | 150 | 300 |
